List of naval ship classes of Germany

The list of naval ship classes of Germany includes all classes of naval ships produced or operated in Germany from the late 19th century to modern day.

Aircraft carriers

Graf Zeppelin class

Displacement: 23,200 tons
Armament: 16 x 15 cm guns, 10 x 10.5 cm guns, 22 x 3.7 cm AA guns, 28 x 2 cm AA guns
Aircraft: Up to 37, including Bf 109T, Ju 87C, and Fi 167
Performance: Speed 35 knots (65 km/h); Range 8,000 nautical miles (15,000 km) at 19 knots (35 km/h)
Ships in class: 2: Graf Zeppelin and Flugzeugträger B
Service: Neither vessel was commissioned into service

Surface combatants

Battleships (Schlachtschiffe)

See list of battleships of Germany for detailed listings

Battlecruisers (Schlachtkreuzer)

Monitors (Küstenpanzerschiffe)

SMS Oldenburg

Displacement: 5,652 tons
Armament: 8 x 24 cm guns
Armor:
Performance: Speed 13.5 knots (25 km/h)
Ships in class: 1: Oldenburg
Service: Launched 1884

Siegfried class

Displacement: 3,740 tons
Armament: 3 x 24 cm guns; 10 x 8.8 cm guns; 4 x 45 cm torpedo tubes
Armor: 530 mm belt; 200 mm turret; 50 mm deck
Performance: Speed 15 knots (28 km/h); Range 1,490 nautical miles (2,760 km) at 10 knots (19 km/h)
Ships in class: 6: Siegfried, Beowulf, Frithjof, Heimdall, Hildebrand, Hagen
Service: Commissioned 1890 to 1896

Odin class

Displacement: 3,740 tons - 4,250 tons
Armament: 3 x 24 cm guns; 8-10 x 8.8 cm guns; 3-4 x 45 cm torpedo tubes
Armor: 530 mm belt; 200 mm turret; 50 mm deck
Performance: Speed 15 knots (28 km/h); Range 1,490 nautical miles (2,760 km) at 10 knots (19 km/h)
Ships in class: 2: Odin, and Ägir
Service: Commissioned 1890 to 1896

Heavy cruisers (Schwere Kreuzer)

Admiral Hipper class

Displacement: 18,200 tons (18,400 tons for Prinz Eugen)
Armament: 8 x 20 cm (8") guns; 12 x 10.5 cm guns; 6 x 4 cm AA guns; 8 x 3.7 cm AA guns; 32 x 2 cm AA guns; 12 x 53 cm (21") torpedo tubes (Prinz Eugen shipped 17 x 4 cm guns, 28 x 2 cm guns, and no 3.7 cm guns)
Armor: 80 mm belt; 105 mm turret; 50 mm deck
Performance: Speed 32 knots (59 km/h); Range 8,000 nautical miles (15,000 km) at 20 knots (Prinz Eugen speed was 33 knots (61 km/h) and range was 7,200 nautical miles (13,330 km) at 20 knots)
Ships in class: 5: Admiral Hipper, Blücher, Prinz Eugen, Seydlitz, and Lützow
Service: Three ships completed, commissioned 1939 to 1940, two lost in World War II

Deutschland class

Displacement: 14,500 tons
Armament: 6 x 28 cm (11") guns; 8 x 15 cm guns; 6 x 8.8 cm guns; 8 x 3.7 cm AA guns; 8 x 2 cm AA guns; 8 x 53 cm (21") torpedo tubes
Armor: 80 mm belt; 140 mm turret; 40 mm deck
Performance: Speed 28 knots (52 km/h); Range 18,650 nautical miles (34,540 km) at 15 knots (28 km/h)
Ships in class: 3: Deutschland (renamed Lützow), Admiral Scheer, and Admiral Graf Spee
Service: Commissioned 1933 to 1936, both lost during World War II

Armored cruisers (Panzerkreuzer)

SMS Blücher

SMS Blücher

Displacement: 17,500 tons
Armament: 12 x 21 cm guns; 8 x 15 cm guns; 16 x 8.8 cm guns; 4 x 45 cm torpedo tubes
Armor: 180 mm belt; 180 mm turret; 70 mm deck
Performance: Speed 26 knots (48 km/h); Range 6,600 nautical miles (12,220 km) at 12 knots (22 km/h)
Ships in class: 1
Service: Commissioned 1909, sunk 1915

Scharnhorst class

SMS Scharnhorst

Displacement: 12,985 tons
Armament: 8 x 21 cm guns; 6 x 15 cm guns; 18 x 8.8 cm guns; 4 x 3.7 cm guns; 4 x machineguns; 4 x 45 cm torpedo tubes
Armor: 150 mm belt; 170 mm turret; 70 mm deck
Performance: Speed 23 knots (43 km/h); Range 5,120 nautical miles (9,480 km) at 12 knots (22 km/h)
Ships in class: 2: Scharnhorst and Gneisenau
Service: Commissioned 1907 to 1908, both lost in World War I at the Battle of the Falkland Islands

Roon class

Displacement: 10,266 tons
Armament: 4 x 21 cm guns; 10 x 15 cm guns; 14 x 8.8 cm guns; 4 x 3.7 cm guns; 4 x 45 cm torpedo tubes
Armor: 100 mm belt; 150 mm turret; 60 mm deck
Performance: Speed 21 knots (39 km/h); Range 4,200 nautical miles (7,780 km) at 12 knots (22 km/h)
Ships in class: 2: Roon and Yorck
Service: Commissioned 1905 to 1906, Yorck lost in World War I

Prinz Adalbert class

Displacement: 9,800 tons
Armament: 4 x 21 cm guns; 10 x 15 cm guns; 12 x 8.8 cm guns; 4 x 3.7 cm guns; 4 x 45 cm torpedo tubes
Armor: 100 mm belt; 150 mm turret; 60 mm deck
Performance: Speed 20 knots (37 km/h); Range 4,200 nautical miles (7,780 km) at 12 knots (22 km/h)
Ships in class: 2: Prinz Adalbert and Friedrich Carl
Service: Commissioned 1903 to 1904, both lost in World War I

SMS Prinz Heinrich

Displacement: 9,800 tons
Armament: 2 x 24 cm guns; 10 x 15 cm guns; 10 x 8.8 cm guns; 10 x 3.7 cm guns; 4 x 45 cm torpedo tubes
Armor: 100 mm turret; 50 mm deck
Performance: Speed 20 knots (37 km/h); Range 4,580 nautical miles (8,480 km) at 10 knots (19 km/h)
Ships in class: 1
Service: Commissioned 1902

SMS Fürst Bismarck

Displacement: 11,460 tons
Armament: 4 x 24 cm guns; 12 x 15 cm guns; 10 x 8.8 cm guns; 4 x machineguns; 6 x 45 cm torpedo tubes
Armor: 200 mm belt; 200 mm turret; 50 mm deck
Performance: Speed 18 knots (33 km/h); Range 4,560 nautical miles (8,450 km) at 10 knots (19 km/h)
Ships in class: 1
Service: Commissioned 1900

Protected cruisers (Geschützte Kreuzer)

Victoria Louise class

SMS Hertha

Displacement: 6,790 tons
Armament: 2 x 21 cm (8") guns; 6 x 15 cm guns; 10 x 8.8 cm guns; 4 x machineguns; 5 x 45 cm torpedo tubes
Armor: 100 mm turret; 100 mm deck
Performance: Speed 19 knots (35 km/h); Range 3,400 nautical miles (6,300 km) at 12 knots (22 km/h)
Ships in class: 5: Victoria Louise, Hertha, Freya, Vineta, and Hansa
Service: Commissioned 1899

SMS Kaiserin Augusta

Displacement: 6,300 tons
Armament: 4 x 15 cm guns; 6 x 10 cm guns; 5 x 35 cm torpedo tubes (1896 modification added 8 x 15 cm guns and 8 x 8.8 cm guns, removed all 10 cm guns; 1916 modification added 4 x 10 cm guns and 1 x 8.8 cm gun, removed 11 x 15 cm guns and all torpedo tubes)
Armor: 70 mm deck
Performance: Speed 21 knots (39 km/h); Range 3,240 nautical miles (6,000 km) at 12 knots (22 km/h)
Ships in class: 1
Service: Commissioned 1895

Light cruisers (Leichte Kreuzer)

Leipzig class

Displacement: 8,400 tons (9,000 tons for Nürnberg)
Armament: 9 x 15 cm (6") guns; 6 x 8.8 cm guns; 8 x 3.7 cm guns; 4 x 2 cm guns; 12 x 53 cm (21") torpedo tubes; 120 mines (Nürnberg shipped an additional 2 x 8.8 cm guns and 2 x 4 cm AA guns)
Aircraft: 2 catapult launched Arado Ar 196
Armor: 50 mm belt; 30 mm turret; 20 mm deck
Performance: Speed 32 knots (59 km/h); Range 5,700 nautical miles (10,560 km) at 19 knots (35 km/h)
Ships in class: 2: Leipzig and Nürnberg
Service: Commissioned 1931 and 1935, Leipzig damaged in 1944 in collision and reduced to flak ship, both survived World War II

Königsberg class

SMS Köln

Displacement: 7,700 tons
Armament: 9 x 15 cm (6") guns; 2 x 8.8 cm guns; 12 x 50 cm torpedo tubes; 120 mines (1934 modification added 8 x 3.7 cm AA guns and replaced torpedoes with 53 cm tubes; 1940 modification added 4 x 8.8 cm guns; 1945 modification added 10 x 2 cm AA guns)
Armor: 70 mm belt; 20 mm turret; 40 mm deck
Performance: Speed 32 knots (59 km/h); Range 7,300 nautical miles (13,520 km) at 17 knots (31 km/h)
Ships in class: 3: Königsberg, Köln, Karlsruhe
Service: Commissioned 1929 to 1930, all lost in World War II

Cöln class

Displacement: 7,485 tons
Armament: 8 x 15 cm guns; 3 x 8.8 cm guns; 4 x 60 cm torpedo tubes; 200 mines
Performance: Speed 29 knots (54 km/h); Range 6,000 nautical miles (11,000 km) at 12 knots (22 km/h)
Ships in class: 10: Cöln, Dresden, Wiesbaden, Magdeburg, Leipzig, Rostock, Frauenlob, Ersatz Köln, Ersatz Emden, and Ersatz Karlsruhe
Service: Seven launched, two commissioned 1918, both scuttled at Scapa Flow

Königsberg class

Displacement: 7,125 tons
Armament: 8 x 15 cm guns; 2 x 8.8 cm guns; 4 x 50 cm torpedo tubes; 200 mines
Armor: 60 mm belt; 40 mm deck
Performance: Speed 28 knots (52 km/h); Range 4,850 nautical miles (8,980 km) at 12 knots (22 km/h)
Ships in class: 4: Königsberg, Emden, Karlsruhe, and Nürnberg
Service: Commissioned 1916 to 1917, two scuttled at Scapa Flow

Emden

Displacement: 7,100 tons
Armament: 8 x 15 cm (6") guns; 3 x 8.8 cm guns; 6 x 2 cm AA guns; 4 x 50 cm torpedo tubes; 120 mines (1944 modification replaced 8.8 cm guns with 10.5 cm guns, added 2 x 3.7 cm AA guns and 14 x 2 cm AA guns, and replaced torpedoes with 53 cm (21") tubes)
Armor: 50 mm belt; 40 mm deck
Performance: Speed 29 knots (54 km/h); Range 6,750 nautical miles (12,500 km) at 14 knots (26 km/h)
Ships in class: 1
Service: Commissioned 1925, damaged by bombing April 1945, scuttled May 1945

Graudenz class

Displacement: 6,380 tons
Armament: 12 x 10.5 cm guns; 2 x 50 cm torpedo tubes; 120 mines (1915 modification replaced 10.5 cm guns with 7 x 15 cm guns and added 2 x 8.8 cm guns and 2 x 50 cm tubes)
Armor: 60 mm belt; 40 mm deck
Performance: Speed 27 knots (50 km/h); Range 5,500 nautical miles (10,190 km) at 12 knots (22 km/h)
Ships in class: 2: Graudenz and Regensburg
Service: Commissioned 1914 to 1915, one lost in World War II

Karlsruhe class

Displacement: 6,190 tons
Armament: 12 x 10.5 cm guns; 2 x 45 cm torpedo tubes
Armor: 60 mm belt; 60 mm deck
Performance: Speed 28 knots (52 km/h); Range 5,000 nautical miles (9,000 km) at 12 knots (22 km/h)
Ships in class: 2: Karlsruhe and Rostock
Service: Commissioned 1914, both lost in World War I

Brummer class

Displacement: 5,850 tons
Armament: 4 x 15 cm guns; 2 x 8.8 cm guns; 2 x 50 cm torpedo tubes; 400 mines
Armor: 38 mm belt; 16 mm deck
Performance: Speed 28 knots (52 km/h); Range 5,800 nautical miles (10,740 km) at 12 knots (22 km/h)
Ships in class: 2: Brummer and Bremse
Service: Commissioned 1916, both scuttled at Scapa Flow

Pillau class

SMS Elbing

Displacement: 5,250 tons
Armament: 8 x 15 cm guns; 4 x 5.2 cm guns; 2 x 50 cm torpedo tubes; 120 mines
Armor: 80 mm deck
Performance: Speed 27 knots (50 km/h); Range 4,300 nautical miles (7,960 km) at 12 knots (22 km/h)
Ships in class: 2: Pillau and Elbing
Service: Commissioned 1914 to 1915, one lost in World War I, one lost in World War II

Wiesbaden class

Displacement: 5,200 tons
Armament: 8 x 15 cm guns; 4 x 5.2 cm guns; 4 x 50 cm torpedo tubes; 120 mines
Armor: 60 mm belt; 40 mm deck
Performance: Speed 27 knots (50 km/h); Range 4,800 nautical miles (8,890 km) at 12 knots (22 km/h)
Ships in class: 2: Wiesbaden and Frankfurt
Service: Commissioned 1915, one lost in World War I

Kolberg class

Displacement: 4,900 tons
Armament: 12 x 10.5 cm guns; 4 x 5.2 cm guns; 2 x 45 cm torpedo tubes; 100 mines (1917 modification replaced 10.5 cm guns with 6 x 15 cm guns and 2 x 8.8 cm guns)
Armor: 50 mm deck
Performance: Speed 26 knots (48 km/h); Range 3,250 nautical miles (6,020 km) at 14 knots (26 km/h)
Ships in class: 4: Kolberg, Augsburg, Cöln, and Mainz
Service: Commissioned 1909 to 1911, two lost in World War I

Magdeburg class

Displacement: 4,570 tons
Armament: 12 x 10.5 cm guns; 2 x 50 cm torpedo tubes; 120 mines
Armor: 60 mm belt; 40 mm deck
Performance: Speed 27 knots (50 km/h); Range 5,820 nautical miles (10,780 km) at 12 knots (22 km/h)
Ships in class: 4: Magdeburg, Breslau, Stralsund, and Strassburg
Service: Commissioned 1912, two lost in World War I

SMS Gefion

Displacement: 4,275 tons
Armament: 10 x 10.5 cm guns; 6 x 5 cm guns; 2 x 45 cm torpedo tubes
Performance: Speed 20 knots (37 km/h); Range 3,500 nautical miles (6,480 km) at 12 knots (22 km/h)
Ships in class: 1
Service: Commissioned 1894

Dresden class

Displacement: 4,250 tons
Armament: 10 x 10.5 cm guns; 10 x machineguns; 2 x 45 cm torpedo tubes
Armor: 100 mm belt; 25 mm deck
Performance: Speed 25 knots (46 km/h); Range 3,600 nautical miles (6,670 km) at 14 knots (26 km/h)
Ships in class: 2: Dresden, and Emden
Service: Commissioned 1908 to 1909, both lost in World War I

Königsberg class

Displacement: 3,800 tons
Armament: 10 x 10.5 cm guns; 8 x 5.2 cm guns; 2 x 45 cm torpedo tubes
Armor: 50 mm deck
Performance: Speed 25 knots (46 km/h); Range 4,170 nautical miles (7,720 km) at 12 knots (22 km/h)
Ships in class: 4: Königsberg, Nürnberg, Stettin, and Stuttgart
Service: Commissioned 1904 to 1907, two lost in World War I

Bremen class

Displacement: 3,700 tons
Armament: 10 x 10.5 cm guns; 2 x 45 cm torpedo tubes (1916 modification added 2 x 15 cm guns and removed 4 x 10.5 cm guns)
Armor: 50 mm deck
Performance: Speed 23 knots (43 km/h); Range 4,690 nautical miles (8,690 km) at 12 knots (22 km/h)
Ships in class: 7: Bremen, Berlin, Danzig, Hamburg, Leipzig, München, and Lübeck
Service: Commissioned 1904 to 1907, two lost in World War I, one lost in World War II

Gazelle class

Displacement: 2,900 tons
Armament: 10 x 10.5 cm guns; 14 x machineguns; 3 x 45 cm torpedo tubes; 120 mines
Armor: 25 mm deck
Performance: Speed 20 knots (37 km/h); Range 3,570 nautical miles (6,610 km) at 12 knots (22 km/h)
Ships in class: 10: Gazelle, Niobe, Nymphe, Thetis, Ariadne, Amazone, Medusa, Frauenlob, Arcona, and Undine
Service: Commissioned 1900 to 1904, three lost in World War I, two lost in World War II

SMS Greif

Displacement: 2,266 tons
Armament: 2 x 10.5 cm guns; 8 x 8.8 cm guns; 10 x 3.7 cm revolving cannon
Performance: Speed 20 knots (37 km/h); Range 3,500 nautical miles (6,480 km) at 12 knots (22 km/h)
Ships in class: 1
Service: Commissioned 1887

SMS Hela

Displacement: 2,080 tons
Armament: 4 x 8.8 cm guns; 6 x 5 cm guns; 3 x 45 cm torpedo tubes
Performance: Speed 20 knots (37 km/h); Range 3,000 nautical miles (6,000 km) at 12 knots (22 km/h)
Ships in class: 1
Service: Commissioned 1896, sunk 1914

Bussard class

Displacement: 1,860 tons
Armament: 8 x 10.5 cm guns; 5 x revolver cannon; 2 x 35 cm torpedo tubes
Performance: Speed 17 knots (31 km/h); Range 3,040 nautical miles (5,630 km) at 9 knots (17 km/h)
Ships in class: 3: Seeadler, Geier, and Condor
Service: Commissioned 1892 to 1893, one lost in World War I

Destroyers (Zerstörer)

Lütjens class (Type 103)

Lütjens (D185)

Displacement: 4,720 tons
Armament: 2 x 127 mm guns; 2 x 20 mm autocannon; 1 x Mark 13 launcher with 40 missiles; 2 x Mark 49 launchers with 42 missiles; 6 x 324 mm torpedo tubes; 1 x ASROC launcher with 8 rockets
Performance: Speed 32 knots (59 km/h)
Ships in class: 3: Lütjens (D185), Mölders (D186), and Rommel (D187)
Service: Commissioned from 1969, last decommissioned 2003

Hamburg class (Type 101)

Displacement: 4,360 tons
Armament: 3 x 100 mm DP guns; 4 x twin 40 mm AA guns; 2 x twin MM38 Exocet launchers; 4 x 533 mm torpedo tubes; 2 x quad 375 mm anti submarine rocket launchers; 10 x depth charges; 90 x mines
Performance: Speed 35 knots (65 km/h); Range 3,400 nautical miles (6,300 km) at 18 knots (33 km/h)
Ships in class: 4: Hamburg (D181), Schleswig-Holstein (D182), Bayern (D183), and Hessen (D184)
Service: Commissioned from 1964, last decommissioned 1994, all scrapped

Type 1936C

Displacement: 3,680 tons
Armament: 6 x 12.8 cm DP guns; 6 x 3.7 cm AA guns; 14 x 2 cm AA guns; 6 x 53 cm torpedo tubes; 60 mines; 4 x depth charge launchers
Performance: Speed 37 knots (69 km/h); Range 2,500 nautical miles (4,630 km) at 19 knots (35 km/h)
Ships in class: 2
Service: Neither completed

Type 1936A

Displacement: 3,600 tons
Armament: 4 x 12.7 cm guns; 4 x 3.7 cm AA guns; 5 x 2 cm AA guns; 8 x 53 cm torpedo tubes; 60 mines; 4 x depth charge launchers
Performance: Speed 37 knots (69 km/h); Range 2,175 nautical miles (4,028 km) at 19 knots (35 km/h)
Ships in class: 8 (Z23 to Z30)
Service: Commissioned 1940 to 1941, 4 lost in World War II, last scrapped 1958

Type 1936A (Mob)

Displacement: 3,590 tons
Armament: 4 x 12.7 cm guns; 4 x 3.7 cm AA guns; 12 x 2 cm AA guns; 8 x 53 cm torpedo tubes; 60 mines; 4 x depth charge launchers
Performance: Speed 37 knots (69 km/h); Range 2,240 nautical miles (4,150 km) at 19 knots (35 km/h)
Ships in class: 7 (Z31 to Z34 and Z37 to Z39)
Service: Commissioned 1942 to 1943, 2 lost in World War II, last scrapped 1964

Type 1936B

Displacement: 3,540 tons
Armament: 5 x 12.7 cm guns; 4 x 3.7 cm AA guns; 16 x 2 cm AA guns; 8 x 53 cm torpedo tubes; 76 mines; 4 x depth charge launchers
Performance: Speed 36 knots (67 km/h); Range 2,600 nautical miles (4,820 km) at 19 knots (35 km/h)
Ships in class: 5 (Z35, Z36, and Z43 to Z45)
Service: Three ships commissioned 1943 to 1944, all lost in World War II

Type 1936

Displacement: 3,400 tons
Armament: 5 x 12.7 cm guns; 4 x 3.7 cm AA guns; 4 x 2 cm AA guns; 8 x 53 cm torpedo tubes; 60 mines; 4 x depth charge launchers
Performance: Speed 40 knots (74 km/h); Range 2,050 nautical miles (3,800 km) at 19 knots (35 km/h)
Ships in class: 6 (Z17 to Z22)
Service: Commissioned 1938 to 1939, 5 lost in World War II, survivor scrapped 1956

Type 1934

Displacement: 3,150 tons
Armament: 5 x 12.7 cm guns; 4 x 3.7 cm AA guns; 6 x 2 cm AA guns; 8 x 53 cm torpedo tubes; 60 mines
Performance: Speed 36 knots (67 km/h); Range 1,900 nautical miles (3,520 km) at 19 knots (35 km/h)
Ships in class: 4 (Z1 to Z4)
Service: Commissioned 1937, three sunk 1940, survivor scrapped 1947

Type 1934A

Displacement: 3,110 tons
Armament: 5 x 12.7 cm guns; 4 x 3.7 cm AA guns; 6 x 2 cm AA guns; 8 x 53 cm torpedo tubes; 60 mines
Performance: Speed 36 knots (67 km/h); Range 2,040 nautical miles (3,780 km) at 19 knots (35 km/h)
Ships in class: 12 (Z5 to Z16)
Service: Commissioned 1937 to 1939, 7 lost in World War II, last scrapped 1958

Type 1942

Displacement: 2,720 tons
Armament: 4 x 12.7 cm guns; 8 x 3.7 cm AA guns; 12 x 2 cm AA guns; 6 x 53 cm torpedo tubes; 50 mines
Performance: Speed 36 knots (67 km/h); Range 5,500 nautical miles (10,190 km) at 19 knots (35 km/h)
Ships in class: 1 (Z51)
Service: Launched but never commissioned

Flottentorpedoboot

Displacement: 2,587 tons
Armament: 4 x 12.7 cm gun; 4 x 3.7 cm AA guns; 16 x 2 cm AA guns; 8 x 53 cm torpedo tubes; 50 mines; 4 x depth charge launchers
Performance: Speed 35 knots (65 km/h); Range 2,350 nautical miles (4,350 km) at 19 knots (35 km/h)
Ships in class: 3
Service: None commissioned

Type 1916

Displacement: 2,415 tons
Armament: 4 x 15 cm gun; 4 x machineguns; 4 x 60 cm torpedo tube; 40 x mines
Performance: Speed 37 knots (69 km/h); Range 2,500 nautical miles (4,630 km) at 20 knots (37 km/h)
Ships in class: 12 (S113 to S115, V116 to V118, G119 to G121, and B122 to B124)
Service: 11 launched, 2 commissioned 1918 to 1919, all scrapped by 1939

Fletcher class (Type 119)

USS Fletcher

Displacement: 2,050 tons
Armament: 5 x 5" guns; 10 x 40 mm AA guns; 10 x 20 mm AA guns; 2 x quintuple 21" torpedo tubes; 6 x depth charge launchers; 2 x depth charge racks
Performance: Speed 36 knots (67 km/h)
Ships in class: 6
Service: Ex-USN World War II destroyers, commissioned from 1959, last decommissioned 1981

Torpedobootzertörer

Displacement: 1,843 tons
Armament: 4 x 10.5 cm guns; 4 x 8.8 cm guns; 6 x 45 cm torpedo tubes; 12 mines
Performance: Speed 37 knots (69 km/h); Range 2,620 nautical miles (4,850 km) at 20 knots (37 km/h)
Ships in class: 8 (B97, B98, V99, V100, and B109 to B112)
Service: Commissioned 1915, one lost in World War I, five scuttled at Scapa Flow

Submarines (Unterseeboot)

Fleet and attack submarines

Type 212

Displacement: 1,830 tons submerged
Armament: 6 x 533 mm torpedo tubes with 12 x torpedoes; 24 x mines external; IDAS missiles
Performance: Speed 20 knots (37 km/h) submerged; Range 420 nautical miles (780 km) at 8 knots (15 km/h) submerged, 8,000 nautical miles (15,000 km) at 8 knots (15 km/h) surfaced; Depth 700 m
Ships in class: 4 (U-31 to U-34), 2 ordered, 6 more planned
Commissioned: 4 commissioned

Type XXI

Displacement: 1,819 tons submerged
Armament: 6 x 533 mm torpedo tubes with 23 x torpedoes or 12 x mines
Performance: Speed 17 knots (31 km/h) submerged; Range 340 nautical miles (630 km) at 5 knots (9 km/h) submerged, 15,500 nautical miles (28,710 km) at 10 knots (19 km/h) surfaced
Ships in class: 118 (U-2501 to U-2531, U-2533 to U-2536, U-2538 to U-2546, U-2548, U-2551, U-2552, U-3001 to U-3035, U-3037 to U-3041, U-3044, and U-3501 to U-3530)
Commissioned: 1944
Fate: Few were ever launched, and all were captured by Allied Forces at the end of the World War II.

Type XVIII

Displacement: 1,652 tons submerged
Armament: 23 x torpedoes
Performance: Speed 24 knots (44 km/h) submerged; Range 202 nautical miles (374 km) at 24 knots (44 km/h) submerged, 3,000 nautical miles (6,000 km) at 17 knots (31 km/h) surfaced
Ships in class: 2 (U-796 and U-797)
Commissioned: None
Fate: Cancelled while building March 1944

Type IXD

Displacement: 1,232 tons submerged
Armament: 6 x 533 mm torpedo tubes with 24 x torpedoes or 48 x mines
Performance: Speed 7 knots (13 km/h) submerged; Range 57 nautical miles (106 km) at 4 knots (7 km/h) submerged, 23,700 nautical miles (43,890 km) at 10 knots (19 km/h) surfaced; Depth 230 m
Ships in class: 30 (U-177 to U-182, U-195 to U-200, U-847 to U-852, U-859 to U-864, and U-871 to U-876
Commissioned: 1942
Fate:

Type IXC/40

Displacement: 1,232 tons submerged
Armament: 6 x 533 mm torpedo tubes with 22 x torpedoes or 44 x mines
Performance: Speed 7 knots (13 km/h) submerged; Range 63 nautical miles (117 km) at 4 knots (7 km/h) submerged, 13,850 nautical miles (25,650 km) at 10 knots (19 km/h) surfaced; Depth 230 m
Ships in class: 87 (U-167 to U-170, U-183 to U-194, U-525 to U-550, U-801 to U-806, U-841 to U-846, U-853 to U-858, U-865 to U-870, U-877 to U-881, U-889, and U-1221 to U-1235)
Commissioned: 1942
Fate:

Type IXC

Displacement: 1,232 tons submerged
Armament: 6 x 533 mm torpedo tubes with 22 x torpedoes or 44 x mines
Performance: Speed 7 knots (13 km/h) submerged; Range 63 nautical miles (117 km) at 4 knots (7 km/h) submerged, 13,450 nautical miles (24,910 km) at 10 knots (19 km/h) surfaced; Depth 230 m
Ships in class: 54 (U-66 to U-68, U-125 to U-131, U-153 to U-166, U-171 to U-176, and U-501 to U-524)
Commissioned: 1941
Fate:

Type IXB

Displacement: 1,178 tons submerged
Armament: 6 x 533 mm torpedo tubes with 22 (32) x torpedoes or 44 x mines
Performance: Speed 8 knots (15 km/h) submerged; Range 78 nautical miles (144 km) at 4 knots (7 km/h) submerged, 10,500 nautical miles (19,450 km) at 10 knots (19 km/h) surfaced; Depth 230 m
Ships in class: 14 (U-64, U-65, U-103 to U-111, and U-122 to U-124)
Commissioned: 1939
Fate:

Type IX

Displacement: 1,152 tons submerged
Armament: 6 x 533 mm torpedo tubes with 22 (32) x torpedoes or 44 x mines
Performance: Speed 8 knots (15 km/h) submerged; Range 78 nautical miles (144 km) at 4 knots (7 km/h) submerged, 10,500 nautical miles (19,450 km) at 10 knots (19 km/h) surfaced; Depth 230 m
Ships in class: 8 (U-37 to U-44)
Commissioned: 1938
Fate: Six sunk in World War II

Type VIIC/42

Displacement: 1,099 tons submerged
Armament: 5 x 533 mm torpedo tubes with 16 x torpedoes or 26 x mines
Performance: Speed 8 knots (15 km/h) submerged; Range 80 nautical miles (150 km) at 4 knots (7 km/h) submerged, 12,600 nautical miles (23,340 km) at 10 knots (19 km/h) surfaced; Depth 270 m
Ships in class: 164 ordered
Commissioned: None
Fate: All contracts cancelled 1943

Type IA

Displacement: 983 tons submerged
Armament: 1 x 10.5 cm deck gun; 6 x 533 mm torpedo tubes with 14 x torpedoes or 28 x mines
Performance: Speed 8 knots (15 km/h) submerged; Range 78 nautical miles (144 km) at 4 knots (7 km/h) submerged, 7,900 nautical miles (14,630 km) at 10 knots (19 km/h) surfaced; Depth 200 m
Ships in class: 2 (U-25, U-26)
Commissioned: 1936
Fate: Both sunk 1940

Type VIIC/41

Displacement: 871 tons submerged
Armament: 1 x 8.8 cm deck gun; 5 x 533 mm torpedo tubes with 14 x torpedoes or 26 x mines
Performance: Speed 8 knots (15 km/h) submerged; Range 80 nautical miles (150 km) at 4 knots (7 km/h) submerged, 8,500 nautical miles (15,740 km) at 10 knots (19 km/h) surfaced; Depth 250 m
Ships in class: 91
Commissioned: 1943
Fate:

Type VIIC

Displacement: 871 tons submerged
Armament: 1 x 8.8 cm deck gun; 5 x 533 mm torpedo tubes with 14 x torpedoes or 26 x mines
Performance: Speed 8 knots (15 km/h) submerged; Range 80 nautical miles (150 km) at 4 knots (7 km/h) submerged, 8,500 nautical miles (15,740 km) at 10 knots (19 km/h) surfaced; Depth 220 m
Ships in class: 568
Commissioned: 1941
Fate:

Type VIIB

Displacement: 857 tons submerged
Armament: 1 x 8.8 cm deck gun; 5 x 533 mm torpedo tubes with 14 x torpedoes or 26 x mines
Performance: Speed 8 knots (15 km/h) submerged; Range 90 nautical miles (170 km) at 4 knots (7 km/h) submerged, 8,700 nautical miles (16,110 km) at 10 knots (19 km/h) surfaced; Depth 220 m
Ships in class: 24 (U-45 to U-55, U-73 to U-76, U-83 to U-87, and U-99 to U-102)
Commissioned: 1938
Fate:

Type VIIA

Displacement: 745 tons submerged
Armament: 1 x 8.8 cm deck gun; 5 x 533 mm torpedo tubes with 11 x torpedoes or 22 x mines
Performance: Speed 8 knots (15 km/h) submerged; Range 94 nautical miles (174 km) at 4 knots (7 km/h) submerged, 6,200 nautical miles (11,480 km) at 10 knots (19 km/h) surfaced; Depth 220 m
Ships in class: 10 (U-27 to U-36)
Commissioned: 1936
Fate: All lost during World War II

Coastal submarines

Type 206A

Type 206A at the Kiel Week

Displacement: 498 tons submerged
Armament: 8 x 533 mm torpedo tubes with 8 x torpedoes; 24 x mines external
Performance: Speed 17 knots (31 km/h) submerged; Range 228 nautical miles (422 km) at 4 knots (7 km/h) submerged, 4,500 nautical miles (8,330 km) at 6 knots (11 km/h) surfaced; Depth > 100 m
Ships in class: 18 (U-13 to U-30)
Commissioned: 1973-1975
Fate: 7 remain in active service

Type 205

Displacement: 500 tons submerged
Armament: 8 x 533 mm torpedo tubes
Performance: Speed 17 knots (31 km/h) submerged; Range 228 nautical miles (422 km) at 4 knots (7 km/h) submerged, 4,200 nautical miles (7,780 km) at 5 knots (9 km/h) surfaced
Ships in class: 11 (U-1, U-2, U-4 to U-11)
Commissioned: 1963
Fate: Decommissioned 2005

Type 201

Displacement: 450 tons submerged
Armament: 8 x 533 mm torpedo tubes with 8 x torpedoes or 16 x mines
Performance: Speed 17 knots (31 km/h) submerged
Ships in class: 4 (U-1 to U-4)
Commissioned: 1962
Fate: Decommissioned by 1967 for rebuilding to Type 205A standard

Type IID

Displacement: 364 tons submerged
Armament: 3 x 533 mm torpedo tubes with 5 x torpedoes or 12 x mines
Performance: Speed 7 knots (13 km/h) submerged; Range 56 nautical miles (104 km) at 4 knots (7 km/h) submerged, 5,650 nautical miles (10,460 km) at 8 knots (15 km/h) surfaced; Depth 150 m
Ships in class: 16 (U-137 to U-152)
Commissioned: 1939

Type IIC

Displacement: 341 tons submerged
Armament: 3 x 533 mm torpedo tubes with 5 x torpedoes or 12 x mines
Performance: Speed 7 knots (13 km/h) submerged; Range 42 nautical miles (78 km) at 4 knots (7 km/h) submerged, 3,800 nautical miles (7,040 km) at 8 knots (15 km/h) surfaced; Depth 150 m
Ships in class: 8 (U-56 to U-63)
Commissioned: 1937

Type IIB

Displacement: 328 tons submerged
Armament: 3 x 533 mm torpedo tubes with 5 x torpedoes or 12 x mines
Performance: Speed 7 knots (13 km/h) submerged; Range 43 nautical miles (80 km) at 4 knots (7 km/h) submerged, 3,100 nautical miles (5,740 km) at 8 knots (15 km/h) surfaced; Depth 150 m
Ships in class: 20 (U-7 to U-24, U-120, U-121)
Commissioned: 1935

Type IIA

Displacement: 303 tons submerged
Armament: 3 x 533 mm torpedo tubes with 5 x torpedoes or 12 x mines
Performance: Speed 7 knots (13 km/h) submerged; Range 35 nautical miles (65 km) at 4 knots (7 km/h) submerged, 1,600 nautical miles (2,960 km) at 8 knots (15 km/h) surfaced; Depth 150 m
Ships in class: 6 (U-1 to U-6)
Commissioned: 1935
Fate: Three lost in World War II, survivors stricken 1944

Type XXIII

Displacement: 258 tons submerged
Armament: 2 x 533 mm torpedo tubes with 2 x torpedoes
Performance: Speed 12 knots (22 km/h) submerged; Range 194 nautical miles (359 km) at 4 knots (7 km/h) submerged, 2,600 nautical miles (4,820 km) at 8 knots (15 km/h) surfaced
Ships in class: 61 (U-2321 to U-2369, U-2371, U-4701 to U-4707, and U-4709 to U-4712)
Commissioned: 1944
Fate: 7 lost in World War II

Special purpose submarines

Type UC-90 (or UC-III) long-range mine laying submarine

Displacement: 571 tons submerged
Armament: 3 x 533 mm torpedo tubes; 1 x 3.4 in gun; and 14 x mines
Performance: Speed 11.5 knots (21.3 km/h) surfaced; 6.6 knots (12.2 km/h) submerged
Ships in class: UC-97 and ???
Commissioned: never commissioned
Fate: launched on 17 March 1918; sunk 7 June 1921 in target practice by the USS Wilmette in Lake Michigan about 20 nautical miles (37 km) east of Highland Park, IL.

Type UE-II long-range mine laying submarine

Displacement: 2,177 tons submerged
Armament: ??? and mines
Performance:
Ships in class: U-117 and ???
Commissioned: 28 March 1918
Fate: U-117 sunk in 1919 as a target in tests by Billy Mitchell.

Type XB mine laying submarine

Displacement: 2,177 tons submerged
Armament: 2 x 533 mm torpedo tubes with 15 x torpedoes and 66 x SMA mines
Performance: Speed 7 knots (13 km/h) submerged; Range 93 nautical miles (172 km) at 4 knots (7 km/h) submerged, 18,450 nautical miles (34,170 km) at 10 knots (19 km/h) surfaced; Depth 220 m
Ships in class: 8 (U-116 to U-119, U-219, U-220, U-233, and U-234)
Commissioned: 1941
Fate: Six lost in World War II

Type XIV supply submarine

Displacement: 1,932 tons submerged
Armament: 3 x AA guns
Performance: Speed 6 knots (11 km/h) submerged; Range 55 nautical miles (102 km) at 4 knots (7 km/h) submerged, 12,350 nautical miles (22,870 km) at 10 knots (19 km/h) surfaced; Depth 240 m
Ships in class: 10 (U-459 to U-464 and U-487 to U-490)
Commissioned: 1941
Fate:

Type VIIF torpedo supply submarine

Displacement: 1,181 tons submerged
Armament: 5 x 533 mm torpedo tubes with 14 x torpedoes
Performance: Speed 8 knots (15 km/h) submerged; Range 75 nautical miles (139 km) at 4 knots (7 km/h) submerged, 14,700 nautical miles (27,220 km) at 10 knots (19 km/h) surfaced; Depth 200 m
Ships in class: 4 (U-1059 to U-1062)
Commissioned: 1943
Fate:

Type VIID mine laying submarine

Displacement: 1,080 tons submerged
Armament: 5 x 533 mm torpedo tubes with 14 x torpedoes or 26 x mines and 15 x SMA mines
Performance: Speed 8 knots (15 km/h) submerged; Range 69 nautical miles (128 km) at 4 knots (7 km/h) submerged, 11,200 nautical miles (20,740 km) at 10 knots (19 km/h) surfaced; Depth 200 m
Ships in class: 6 (U-213 to U-218)
Commissioned: 1941
Fate: Five lost in World War II

Type XVIIB research submarine

Displacement: 337 tons submerged
Armament: None
Performance: Speed 25 knots (46 km/h) submerged; Range 123 nautical miles (228 km) at 25 knots (46 km/h) submerged, 3,000 nautical miles (6,000 km) at 8 knots (15 km/h) surfaced
Ships in class: 12 (U-1405 to U-1416)
Commissioned: Three from 1944
Fate: Three scuttled May 1945, nine cancelled while building

Hans Techel class (Type 202)

Displacement: 137 tons submerged
Armament: 2 x short torpedo tubes with 2 x torpedoes or 4 x mines
Performance: Speed 13 knots (24 km/h) submerged
Ships in class: 2: Hans Techel (S172) and Friedrich Schürer (S173)
Service: Commissioned from 1965, both decommissioned 1966 and scrapped

Type XVIIA research submarine

Displacement: 309 tons submerged
Armament: None
Performance: Speed 25 knots (46 km/h) submerged; Range 127 nautical miles (235 km) at 20 knots (37 km/h) submerged, 2,910 nautical miles (5,390 km) at 8 knots (15 km/h) surfaced
Ships in class: 4 (U-792 to U-795)
Commissioned: 1943
Fate: All scuttled May 1944

Midget submarines

Type XXVIIB5 Seehund

Displacement: 17 tons submerged
Armament: 2 x torpedoes
Performance: Range 300 m at 7 knots (13 km/h); Depth 50 m
Ships in class: 285
Commissioned: 1944
Fate: 35 lost during World War II

Type XXVII Hecht

Displacement:
Armament: 1 x torpedo or 1 x limpet mine
Performance: Range 40 nautical miles (70 km) at 6 knots (11 km/h) submerged or 78 nautical miles (144 km) at 3 knots (6 km/h) surfaced
Ships in class: 53
Commissioned: 1944
Fate:

Molch

Displacement: 11 tons
Armament: 2 x torpedoes
Performance: Range 40 nautical miles (70 km) at 5 knots (9 km/h) submerged
Ships in class: 393
Commissioned: 1944
Fate:

Biber

Displacement: 6.5 tons
Armament: 2 x torpedoes
Performance: Range 9 nautical miles (17 km) at 5 knots (9 km/h) submerged or 130 nautical miles (240 km) at 6 knots (11 km/h) surfaced
Ships in class: 324
Commissioned: 1944
Fate:

Surface combatants

Frigates (Fregatten)

Sachsen class (Type 124)

Hamburg (F220)

Displacement: 5,690 tons
Armament: 1 x VLS with 56 missiles; 42 x RAM missiles; 8 x Harpoon missiles; 1 x 76 mm DP gun; 2 x 27 mm autocannon; 2 x triple torpedo launchers
Aircraft: Landing deck with hangar for two Sea Lynx or MH90 helicopters
Performance: Speed 29 knots (54 km/h); Range 4,000 nautical miles (7,000 km) at 18 knots (33 km/h)
Ships in class: 3: Sachsen (F219), Hamburg (F220), Hessen (F221)
Service: Commissioned from 2004, all currently in service

F125 class (Type 125)

Displacement: 7,200 tons
Armament: 8 x anti-ship/land-attack missiles; 42 x RAM missiles; 1 x 127 mm gun; 2 x MLG 27 autocannon; 5 x 12.7 mm remote machineguns; 2 12.7 mm mac

hineguns, water cannons

Aircraft: Landing deck with hangar for two helicopters
Performance: Speed 27 knots (50 km/h); Range 4,000 nautical miles (7,000 km) at 18 knots (33 km/h)
Ships in class: None
Service: Under development

Brandenburg class (Type 123)

Mecklenburg-Vorpommern (F218)

Displacement: 4,900 tons
Armament: 1 x Mark 41 VLS with 16 missiles; 2 x Mark 49 launcher with 42 missiles; 4 x Exocet missiles; 1 x 76 mm DP gun; 2 x 27 mm autocannon; 4 x 324 mm torpedo tubes
Aircraft: Landing deck with hangar for Sea Lynx helicopters
Performance: Speed 29 knots (54 km/h); Range 4,000 nautical miles (7,000 km) at 18 knots (33 km/h)
Ships in class: 4: Brandenburg (F215), Schleswig-Holstein (F216), Bayern (F217), and Mecklenburg-Vorpommern (F218)
Service: Commissioned from 1994, all currently in service

Bremen class (Type 122)

Niedersachsen (F208)

Displacement: 3,680 tons
Armament: 1 x 76 mm guns; rocket launchers; 1 8 cell launch system, 16 Sea Sparrow surface to air missiles; 2 quadruple Harpoon anti-ship missile launchers; 2 MK 49 launcher, 21 RAM each; 2 MLG 27 mm autocannons; 2 Mark 32 324 mm twin torpedo launchers with 8 Mark 46 torpedoes
Aircraft: Landing deck with hangar for Sea Lynx helicopters
Performance: Speed 30 knots (56 km/h); Range more than 4,000 nautical miles (7,000 km) at 18 knots (33 km/h)
Ships in class: 8: Bremen (F207), Niedersachsen (F208), Rheinland-Pfalz (F209), Emden (F210), Köln (F211), Karlsruhe (F212), Augsburg (F213), and Lübeck (F214)
Service: Commissioned from 1982, all currently in service

Köln class (Type 120)

Lübeck (D224)

Displacement: 2,969 tons
Armament: 2 x 100 mm guns; 2 x twin 40 mm AA guns; 2 x 40 mm guns; 4 x 533 mm torpedo tubes; 2 x quad 375 mm anti-submarine rocket launchers; depth charges; mines
Performance: Speed 34 knots (63 km/h); Range 2,700 nautical miles (5,000 km) at 22 knots (41 km/h)
Ships in class: 6: Köln (F220), Emden (F221), Augsburg (F222), Karlsruhe (F223), Lübeck (F224), and Braunschweig (F225)
Service: Commissioned from 1961, last decommissioned 1989

Corvettes (Korvette)

Braunschweig class (Type 130)

Magdeburg (F261)

Displacement: 1,840 tons
Armament: 1 x 76 mm gun; 2 x 27 mm autocannon; 42 x RAM missiles; 4 x RBS-15 missiles; mines
Aircraft: Landing deck with hangar for unmanned aerial vehicles
Performance: Speed 26 knots (48 km/h); Range 4,000 nautical miles (7,410 km) at 15 knots (28 km/h)
Ships in class: 5: Braunschweig (F260), Magdeburg (F261), Erfurt (F262), Oldenburg (F263), and Ludwigshafen (F264)
Service: Five ships in service, at least five more planned

Flottenbegleiter

Displacement: 1,030 tons
Armament: 2 x 10.5 cm guns; 2 x 8.8 cm guns; 4 x 3.7 cm AA guns; 2 x 2 cm AA guns; 4 x depth charge launchers
Performance: Speed 28 knots (52 km/h); Range 1,965 nautical miles (3,639 km) at 13 knots (24 km/h)
Ships in class: 10
Service: Commissioned 1936 to 1938, four lost in World War II, many converted to other roles

Torpedo boats (Torpedoboot)

Type 1916 (Mob)

Displacement: 1,560 tons
Armament: 4 x 10.5 cm gun; 4 x machineguns; 6 x 50 cm torpedo tubes; 40 mines
Performance: Speed 35 knots (65 km/h); Range 2,000 nautical miles (4,000 km) at 20 knots (37 km/h)
Ships in class: 33 (V170 to V177, S178 to S185, and H186 to H202)
Service: 4 commissioned 1919 to 1921

Type 1924

Displacement: 1,320 tons
Armament: 3 x 10.5 cm guns; 2 x 2 cm AA guns; 6 x 53 cm torpedo tubes; 30 mines
Performance: Speed 35 knots (65 km/h); Range 2,000 nautical miles (4,000 km) at 17 knots (31 km/h)
Ships in class: 6
Service: Commissioned 1928 to 1929, all lost in World War II

Type 1916 (Mob)

Displacement: 1,290 tons
Armament: 3 x 10.5 cm gun; 6 x 50 cm torpedo tubes; 40 mines
Performance: Speed 34 knots (63 km/h); Range 1,960 nautical miles (3,630 km) at 20 knots (37 km/h)
Ships in class: 46 (G96, V125 to V130, S131 to S139, V140 to V144, H145 to H147, G148 to G150, I51, S152 to S157, V158 to V165, H166 to H169)
Service: 36 launched, 20 commissioned 1916 to 1918, one lost in World War I, nine scuttled at Scapa Flow

Type 1923

Displacement: 1,250 tons
Armament: 3 x 10.5 cm guns; 2 x 2 cm AA guns; 6 x 53 cm torpedo tubes; 30 mines
Performance: Speed 33 knots (61 km/h); Range 1,800 nautical miles (3,330 km) at 17 knots (31 km/h)
Ships in class: 6
Service: Commissioned 1926 to 1927, all lost in World War II

Type 1937

Displacement: 1,100 tons
Armament: 1 x 10.5 cm gun; 12 x 2 cm AA guns; 6 x 53 cm torpedo tubes; 30 mines
Performance: Speed 35 knots (65 km/h); Range 1,070 nautical miles (1,980 km) at 19 knots (35 km/h)
Ships in class: 9 (T12 to T21)
Service: Commissioned 1941 to 1942, four lost in World War II, all but one scrapped by 1952

Type 1935

Displacement: 1,100 tons
Armament: 1 x 10.5 cm gun; 12 x 2 cm AA guns; 6 x 53 cm torpedo tubes; 30 mines
Performance: Speed 35 knots (65 km/h); Range 1,070 nautical miles (1,980 km) at 19 knots (35 km/h)
Ships in class: 12 (T1 to T12)
Service: Commissioned 1939 to 1940, seven lost in World War II, all but one scrapped by 1952

Type 1913

Displacement: 1,100 tons
Armament: 3 x 8.8 cm gun; 6 x 50 cm torpedo tubes; 24 mines
Performance: Speed 36 knots (67 km/h); Range 1,800 nautical miles (3,330 km) at 20 knots (37 km/h)
Ships in class: 71 (V25 to V30, S31 to S36, G37, G38, G39, G40, G41, G42, V43, V44, V45, V46, V47, V48, S49 to S66, V67 to V84, and G85 to G95)
Service: Commissioned 1914 to 1917

Type 1906

Displacement: 800 tons
Armament: 3 x 10.5 cm guns; 3 x 8.8 cm gun; 3 x 45 cm torpedo tubes
Performance: Speed 34 knots (63 km/h); Range 1,250 nautical miles (2,320 km) at 17 knots (31 km/h)
Ships in class: 59 (S138 to S149, V150 to V164, S165 to S168, G169 to G175, S176 to S179, V180 to V191, and G192 to G197)
Service: Commissioned 1907 to 1911

Type 1911

Displacement: 750 tons
Armament: 2 x 8.8 cm gun; 4 x 45 cm torpedo tubes
Performance: Speed 34 knots (63 km/h); Range 1,150 nautical miles (2,130 km) at 17 knots (31 km/h)
Ships in class: 24 (V1 to V6, G7 to G12, and S13 to S24)
Service: Commissioned 1912 to 1913

Type 1898

Displacement: 600 tons
Armament: 1 x 8.8 cm gun; 4 x 5.2 cm guns; 2 x 5 cm guns; 3 x 45 cm torpedo tubes
Performance: Speed 32 knots (59 km/h); Range 1,500 nautical miles (2,780 km) at 17 knots (31 km/h)
Ships in class: 49 (S90 to S133 and G134 to G137)
Service: Commissioned 1899 to 1907, 12 lost in World War I, last scrapped in 1921

Type 1916

Displacement: 390 tons
Armament: 3 x 8.8 cm gun; 1 x 45 cm torpedo tube; depth charges
Performance: Speed 28 knots (52 km/h); Range 800 nautical miles (1,480 km) at 20 knots (37 km/h)
Ships in class: 68 (A56 to A113)
Service: 40 launched, 36 commissioned 1917 to 1918, 9 lost in World War II, most scrapped by 1923

Type 1915

Displacement: 250 tons
Armament: 3 x 8.8 cm gun; 1 x 45 cm torpedo tube; depth charges
Performance: Speed 26 knots (48 km/h); Range 690 nautical miles (1,280 km) at 20 knots (37 km/h)
Ships in class: 30 (A26 to A55)
Service: Commissioned 1916 to 1917

Type 1897

Displacement: 175 tons
Armament: 3 x 5 cm gun; 3 x 45 cm torpedo tubes
Performance: Speed 26 knots (48 km/h); Range 1,600 nautical miles (2,960 km) at 12 knots (22 km/h)
Ships in class: 8 (S82 to S89)
Service: Commissioned 1897 to 1898, all scrapped in 1921

Type 1892

Displacement: 175 tons
Armament: 1 x 5 cm gun; 3 x 45 cm torpedo tubes
Performance: Speed 23 knots (43 km/h); Range 1,700 nautical miles (3,150 km) at 12 knots (22 km/h)
Ships in class: 16 (S66 to S81)
Service: Commissioned 1892 to 1896, four lost in World War I, last scrapped in 1921

Type 1885

Displacement: 150 tons
Armament: 1 x 5 cm gun; 2 x 3.7 cm revolver cannon; 3 x 45 cm torpedo tubes
Performance: Speed 22 knots (41 km/h); Range 2,250 nautical miles (4,170 km) at 10 knots (19 km/h)
Ships in class: 59 (S7 to S65)
Service: Commissioned 1885 to 1892, 15 lost in World War I, last scrapped 1921

Type 1914

Displacement: 148 tons
Armament: 1 x 5 cm gun; 2 x 45 cm torpedo tubes; 4 mines
Performance: Speed 20 knots (37 km/h); Range 440 nautical miles (810 km) at 19 knots (35 km/h)
Ships in class: 25 (A1 to A25)
Service: Commissioned 1915

Fast attack craft (Schnellboot)

Albatros class (Type 143)

S63 Geier and others

Displacement: 398 tons
Armament: 2 x 76 mm guns; 4 x Exocet missiles; 2 x torpedo tubes
Performance: Speed 40 knots (74 km/h)
Ships in class: 10 (S61 to S70)
Service: Commissioned from 1976, last decommissioned 2005

Gepard class (Type 143A)

S71 Gepard

Displacement: 391 tons
Armament: 1 x 76 mm gun; 4 x Exocet missiles; 21 RAM missiles; 2 x MG50 machine guns; mines
Performance: Speed 40 knots (74 km/h)
Ships in class: 10 (S71 to S80)
Service: Commissioned from 1982, currently in service

Tiger class (Type 148)

Displacement: 265 tons
Armament: 1 x 76 mm gun; 4 x Exocet missiles; 1 x 40 mm gun; 8 x mines
Performance: Speed 36 knots (67 km/h)
Ships in class: 20 (S41 to S60)
Service: Commissioned from 1972, last decommissioned 2002

Zobel class (Type 142)

Displacement: 205 tons
Armament: 2 x 40 mm guns; 4 x 533 mm torpedo tubes
Performance: Speed 42 knots (78 km/h)
Ships in class: 10 (S31 to S40)
Service: Commissioned from 1961, last decommissioned 1984

Seeadler class (Type 141)

Displacement: 190 tons
Armament: 2 x 40 mm guns; 4 x 533 mm torpedo tubes; 4 x depth charges
Performance: Speed 43 knots (80 km/h)
Ships in class: 10 (S6 to S11 and S25 to S28)
Service: Commissioned from 1958, last decommissioned 1976

Jaguar class (Type 140)

Displacement: 183 tons
Armament: 2 x 40 mm guns; 4 x 533 mm torpedo tubes; 4 x depth charges (optionally may ship 2 x minelaying ramps instead of two tubes)
Performance: Speed 42 knots (78 km/h); Range 700 nautical miles (1,300 km)
Ships in class: 20 (S1 to S5, S12 to S24, S29, and S30)
Service: Commissioned from 1957, last decommissioned 1975

Type 1939/40

Displacement: 110 tons
Armament: 6 x 3 cm AA gun; 2 x 2 cm AA gun; 2 x 53 cm torpedo tubes; 8 mines
Performance: Speed 41 knots (76 km/h)
Ships in class: 220 (S26 to S29, S38 to S53, S62 to S150; S159 to S232; S301 to S328; S701 to S709)
Service: Commissioned 1941 to 1945, many scrapped before completion

Type 1939

Displacement: 102 tons
Armament: 1 x 2 cm gun; 8 x machineguns; 2 x 53 cm torpedo tubes; 6 mines
Performance: Speed 36 knots (67 km/h); Range 800 nautical miles (1,480 km) at 30 knots (56 km/h)
Ships in class: 16 (S30 to S37, S54 to S61)
Service: Commissioned 1939 to 1941, twelve lost in World War II

Type 1937

Displacement: 105 tons
Armament: 1 x 2 cm gun; 1 x machinegun; 2 x 53 cm torpedo tubes
Performance: Speed 40 knots (74 km/h); Range 700 nautical miles (1,300 km) at 35 knots (65 km/h)
Ships in class: 8 (S18 to S25)
Service: Commissioned 1938 to 1939, one lost in World War II

Type 1934

Displacement: 105 tons
Armament: 1 x 2 cm gun; 1 x machinegun; 2 x 53 cm torpedo tubes
Performance: Speed 37 knots (69 km/h); Range 500 nautical miles (930 km) at 32 knots (59 km/h)
Ships in class: 4 (S14 to S17)
Service: Commissioned 1936 to 1938, two lost in World War II, others turned over to Allies

Type 1933

Displacement: 90 tons
Armament: 1 x 2 cm gun; 4 x machineguns; 2 x 53 cm torpedo tubes
Performance: Speed 36 knots (67 km/h); Range 600 nautical miles (1,110 km) at 30 knots (56 km/h)
Ships in class: 7 (S7 to S13)
Service: Commissioned 1934 to 1935, one scuttled in World War II, remainder turned over to Allies

Nasty class (Type 152)

Displacement: 398 tons
Armament: 2 x 76 mm guns; 4 x Exocet missiles; 2 x torpedo tubes
Performance: Speed 40 knots (74 km/h)
Ships in class: 2: Hugin and Munin
Service: Commissioned from 1960, both decommissioned 1964

Type 1931

Displacement: 57 tons
Armament: 1 x 2 cm gun; 2 x 53 cm torpedo tubes
Performance: Speed 33 knots (61 km/h); Range 580 nautical miles (1,070 km) at 22 knots (41 km/h)
Ships in class: 4 (S2 to S5)
Service: Commissioned 1932, all to Spain in 1936

Leichte Schnellboote

Displacement: 12 tons
Armament: 2 x 2 cm guns; 1 x machinegun; 2 x 45 cm torpedo tubes; 4 mines
Performance: Speed 40 knots (74 km/h); Range 300 nautical miles (560 km) at 30 knots (56 km/h)
Ships in class: 12
Service: Commissioned 1940 to 1944, all but one lost during World War II

Mine warfare vessels

Minehunters (Minensuchboot)

Sperrbrecher

Displacement: 7,500 tons (typical)
Armament: 2 x 10.5 cm guns; 2 x 3.7 cm AA gun; 15 x 2 cm AA guns (typical)
Performance: Speed 14 knots (typical)
Ships in class: Around 100
Service: Converted from merchant ships through World War II, about 50 lost, many returned to merchant duties after the war

Type 1935

Displacement: 870 tons
Armament: 2 x 10.5 cm guns; 1 x 3.7 cm AA gun; 6 x 2 cm AA guns; 4 x depth charge launchers; 30 mines
Performance: Speed 18 knots (33 km/h); Range 5,000 nautical miles (9,000 km) at 10 knots (19 km/h)
Ships in class: 69
Service: Commissioned 1938 to 1943, 34 lost during World War II, five served with German Federal Navy

Type 1943

Displacement: 821 tons
Armament: 2 x 10.5 cm guns; 2 x 3.7 cm AA gun; 8 x 2 cm AA guns; 4 x depth charge launchers; 24 mines
Performance: Speed 17 knots (31 km/h); Range 3,600 nautical miles (6,670 km) at 11 knots (20 km/h)
Ships in class: 17
Service: Commissioned 1944 to 1945, one lost during World War II

Type 1941

Displacement: 775 tons
Armament: 2 x 10.5 cm guns; 4 x 3.7 cm AA gun; 10 x 2 cm AA guns; 4 x depth charge launchers
Performance: Speed 17 knots (31 km/h); Range 4,000 nautical miles (7,000 km) at 10 knots (19 km/h)
Ships in class: 131
Service: Commissioned 1941 to 1944, 63 lost during World War II, five served with German Federal Navy

Ensdorf class (Type 352)

Siegburg (M1098), an Ensdorf-class minesweeper

Displacement: 650 tons
Armament:
Bofors 40 mm/L70 dual-purpose gun (to be upgraded to 2 Mauser MLG27 27 mm remote-controlled guns)
Fliegerfaust 2 surface-to-air missiles (MANPADS)
Mine-laying capabilities (60 mines)
Performance: Speed 18 knots (33 km/h)
Ships in class: 5: Ensdorf (M1094), Auerbach/Oberpfalz (M1093), Hameln (M1092), Pegnitz (M1090) and Siegburg (M1098)
Service: Commissioned from 1990, all in active service

Frankenthal class (Type 332)

Grömitz (M1064), already equipped with the MLG 27

Displacement: 660 tons
Armament: 1 x 40 mm DP gun; mines (currently upgrading to 1 x MLG 27 mm autocannon)
Performance: Speed 18 knots (33 km/h)
Ships in class: 12: Frankenthal (M1066), Weiden (M1060), Rottweil (M1061), Bad Bevensen (M1063), Bad Rappenau (M1067), Grömitz (M1064), Datteln (M1068), Dillingen (M1065), Homburg (M1069), Sulzbach-Rosenberg (M1062), Fulda (M1058), and Weilheim (M1059)
Service: Commissioned from 1992, all in active service

Kulmbach class (Type 333)

Kulmbach-class minehunters

Displacement: 645 tons
Armament: 2 x 40 mm DP guns (currently upgrading to 1 x MLG 27 mm autocannon); 2 x anti-aircraft missile launchers; mines
Performance: Speed 18 knots (33 km/h)
Ships in class: 5: Kulmbach (M1091), Überherrn (M1095), Herten (M1099), Passau (M1096), and Laboe (M1097)
Service: Commissioned from 1989, all in active service

Seehund ROV (part of the TROIKA Plus system of the Ensdorf-class minesweepers)

Three Seehund ROVs

Length: 25 m
Displacement: 97.8t
Propulsion: Schottel Z-drive
Max speed: 9-10kts
Ships in class: 18: all in active service

Seehund can be controlled remotely or manually by an onboard crew (usually 3) for maneuvering in harbours or in training (the Seehund is too large to be carried by Ensdorf-class vessels). A life raft is carried for this reason.

Type 1916

Displacement: 630 tons
Armament: 2 x 8.8 cm guns; 30 x mines
Performance: Speed 16 knots (30 km/h); Range 2,000 nautical miles (4,000 km) at 14 knots (26 km/h)
Ships in class: 120 (M57 to M176)
Service: 91 launched, 81 commissioned 1918 to 1920, 8 lost in World War I

Type 1915

Displacement: 510 tons
Armament: 2 x 10.5 cm guns; 30 x mines (some boats shipped 3 x 8.8 cm guns instead of 2 x 10.5 cm guns)
Performance: Speed 16 knots (30 km/h); Range 2,000 nautical miles (4,000 km) at 14 knots (26 km/h)
Ships in class: 30 (M27 to M56)
Service: Commissioned 1916, 10 lost in World War I

Type 1914

Displacement: 475 tons
Armament: 2 x 8.8 cm guns; 1 x 3.7 cm revolver cannon; 30 x mines
Performance: Speed 17 knots (31 km/h); Range 1,680 nautical miles (3,110 km) at 14 knots (26 km/h)
Ships in class: 26 (M1 to M26)
Service: Commissioned 1914 to 1917, 11 lost in World War I

Flachgehende Minensuchboote

Displacement: 205 tons
Armament: 1 x 8.8 cm gun
Performance: Speed 14 knots (26 km/h); Range 650 nautical miles (1,200 km) at 14 knots (26 km/h)
Ships in class: 66 (FM1 to FM66)
Service: 54 launched, commissioned 1918 to 1919, 6 lost in World War II

Minenräumboot

Displacement: 155 tons
Armament: 1 x 3.7 cm AA gun; 3 x 2 cm AA guns; 1 x 8.6 cm Föhn launcher
Performance: Speed 19 knots (35 km/h)
Ships in class: 300
Service: About 160 lost during World War II

Mine layers (Minenleger)

Albatross

Displacement: 2,500 tons
Armament: 8 x 8.8 cm guns; 288 x mines
Performance: Speed 20 knots (37 km/h); Range 3,680 nautical miles (6,820 km) at 9 knots (17 km/h)
Ships in class: 1
Service: Commissioned 1908, scrapped 1921

Auxiliary mine layer (Hilfsminenleger)

Displacement: 300 to 4,200 tons
Ships in class: 16 conversions
Service: Converted from various merchant and passenger ships, commissioned as mine layers in 1914, all survived World War I, most returned to civil duties

Küstenminenleger

Displacement: 19 tons
Armament: 2 x 2 cm guns; 4 mines
Performance: Speed 32 knots (59 km/h); Range 225 nautical miles (417 km) at 25 knots (46 km/h)
Ships in class: 36 (KM1 to KM36)
Service: Commissioned 1941 to 1943

Amphibious warfare vessels

Landing craft (Landungsboote)

Barbe class (Type 520)

Barbe-class landing craft

Displacement: 430 tons
Armament: 2 x 20 mm autocannon; mines
Capacity: 150 t
Performance: Speed 11 knots (20 km/h)
Ships in class: 22
Service: Commissioned from 1965, two remain in active service

Type 554

Typical LCU

Displacement: 375 tons
Armament: 2 x 12.7 mm machineguns
Capacity: 125 t or 400 troops
Performance: Speed 11 knots (20 km/h); Range 1,200 nautical miles (2,220 km) at 9 knots (17 km/h)
Ships in class: 1
Service: 1958 to 1964

Type 521

Typical LCM-8

Displacement: 111 tons
Armament: Small arms
Capacity: 53 t
Performance: Speed 11 knots (20 km/h)
Ships in class: 28
Service: Commissioned from 1965, decommissioned

Type 552

Displacement: 13 tons
Capacity: 0.4 t or 36 troops
Performance: Speed 10 knots (19 km/h); Range 80 nautical miles (148 km)
Ships in class: 9
Service: 1958 to 1964

Auxiliary ships

Tenders and replenishment ships

Berlin class (Type 702)

Berlin (A1411)

Displacement: 20,240 tons
Armament: 4 x 27 mm autocannon; Fliegerfaust 2 missiles
Aircraft: Helicopter deck with hangar for two large helicopters
Ships in class: 2: Berlin (A1411) and Frankfurt am Main (A1412)
Service: Commissioned from 2001, both in active service, 2 more planned (Bonn (A1413) and 1 other)

Rhön class (Type 704A)

Displacement: 14,170 tons
Capacity: 44,760 m³
Performance: Speed 16 knots (30 km/h)
Ships in class: 2: Rhön (A1443) and Spessart (A1442)
Service: Commissioned from 1966, two remain in active service

Elbe class (Type 404)

Elbe (A511)

Displacement: 3,586 tons
Armament: 2 x Fliegerfaust missiles; 2 x 20 mm autocannon
Aircraft: Helicopter deck, no hangar
Capacity: 700 m³ fuel; 60 m³ aviation fuel; 280 m³ fresh water; 160t ammunition; 40t supplies
Performance: Speed 15 knots (28 km/h); Range 2,600 nautical miles (4,820 km)
Ships in class: 12: Elbe (A511), Mosel (A512), Rhein (A513), Werra (A514), Main (A515), and Donau (A516)
Service: Commissioned from 1993, all in active service

Walchensee class (Type 703)

Displacement: 2,190 tons
Capacity: 1,100t fuel; 60t fresh water
Performance: Speed 12 knots (22 km/h)
Ships in class: 4: Walchensee (A1424), Ammersee (A1425), Tegernsee (A1426), and Westensee (A1427)
Service: Commissioned from 1966, two remain in active service

Surveillance, reconnaissance, and ELINT ships

Oste class (Type 423)

Displacement: 3,200 tons
Performance: Speed 21 knots (39 km/h); Range 500 nautical miles (930 km)
Ships in class: 3: Oste (A52), Oker (A53), and Alster (A50)
Service: Commissioned from 1988, all in active service

Research ships

Alliance class (Type 753)

Displacement: 2,744 tons
Performance: 17 knots (31 km/h)
Ships in class 1: Alliance (A1456)
Service: In active service

Note: Alliance is a ship of the NATO under German flag and command.

Planet class (Type 751)

Planet (A1437)

Displacement: 3,500 tons
Performance: Speed 15 knots (28 km/h)
Ships in class: 1: Planet (A1437)
Service: Commissioned in 2005, in active service

Helmsand class (Type 748)

Service: 3 in active service: Helmsand (Y862), Kronsort (Y861), Stollergrund (Y863)

Wilhelm Pullwer class (Type 741)

Service: 1 in active service

Tugs

Wangerooge class (Type 722)

Juist (A1456)

Displacement: 798 tons
Performance: Speed 12 knots (22 km/h)
Ships in class: 6: Wangerooge (A1451), Spiekeroog (A1452), Langeoog (A1453), Baltrum (A1454), Norderney (A1455), and Juist (A1456)
Service: Commissioned from 1968, two remain in active service

Helgoland class (Type 720)

Ships in class: 2: Helgoland (A1457) and Fehmarn (A1458)
Service: Commissioned from 1966, Fehmarn remains in active service

Icebreakers

Eisvogel class (Type 721)

Displacement: 560 tons
Performance: Speed 14 knots (26 km/h)
Ships in class: 2: Eisvogel (A1401) and Eisbär (A1402)
Service: Commissioned from 1961, both decommissioned, one sold, one scrapped

Training ships (Schulschiffe)

Deutschland (Type 440)

Displacement: 3,200 tons
Armament: 4 x 100 mm guns; 2 x twin 40 mm guns, 2 x 40 mm guns; 2 x 533 mm torpedo tubes; 2 x quad 375 mm anti submarine rocket launchers, 2 x depth charge rails; mines
Performance: Speed 21 knots (39 km/h)
Ships in class: 1
Service: Commissioned 1966, decommissioned 1990

Gorch Fock (Type 441)

Displacement: 1,760 tons
Performance: Speed 13 knots (24 km/h)
Ships in class: 1
Service: Commissioned 1958, in active service

Transport ships

Westerwald class (Type 760)

Displacement: 4,042 tons
Performance: Speed 17 knots (31 km/h)
Ships in class: 2: Westerwald (A1435) and Odenwald (A1436)
Service: Commissioned from 1967, Westerwald remains in active service

Oil recovery ships

Bottsand class (Type 738)

Bottsand-class oil recovery ship

Displacement: 650 tons
Performance: Speed 10 knots (19 km/h)
Ships in class: 2: Bottsand (Y1643) and Eversand (Y1644)
Service: 2 in active service

This article is issued from Wikipedia - version of the 6/4/2016. The text is available under the Creative Commons Attribution/Share Alike but additional terms may apply for the media files.
