SNCF Class BB 67300

Class BB67300

BB 67304 at Saint-Malo on 1 September 2001.
Type and origin
Power type Diesel
Builder France Brissonneau and Lotz
Build date 1967-1979
Total produced 90
Specifications
AAR wheel arr. B-B
Gauge 1,435 mm (4 ft 8 1⁄2 in) standard gauge
Length 17.090 m (56 ft 7⁄8 in)
Adhesive weight 10 t (9.8 long tons; 11.0 short tons)
Loco weight 80 t (78.7 long tons; 88.2 short tons)
Fuel type Diesel
Prime mover SEMT Pielstick 16 PA 4
Engine type V16 Diesel
Traction motors 2 SW 9209
Cylinders 16
Transmission Electrical
Performance figures
Maximum speed 140 km/h (87 mph)
Power output 1,440 kW (1,930 hp)
Career
Operators SNCF
Class BB67300
Number in class 87 (at 2005)
Numbers 67301-67390
First run 5 December 1967

The SNCF Class BB 67300 diesel locomotives were built by Brissonneau and Lotz between 1967-1969.
