Shepherd's Bush railway station

Shepherd's Bush
Shepherd's Bush Location of Shepherd's Bush in Greater London
Location	Shepherd's Bush
Local authority	London Borough of Hammersmith and Fulham
Managed by	London Overground
Owner	Network Rail
Station code	SPB
DfT category	D
Number of platforms	2
Accessible	Yes [1][2]
Fare zone	2
OSI	Shepherd's Bush LU
National Rail annual entry and exit
2009–10	1.015 million[3]
2010–11	2.241 million[3]
2011–12	3.150 million[3]
2012–13	3.818 million[3]
2013–14	3.932 million[3]
Railway companies
Original company	Network Rail
Key dates
2008	Opened
Other information
Lists of stations	DLR Underground National Rail Tramlink
External links	Departures Layout Facilities Buses
WGS84	51°30′18″N 0°13′03″W / 51.505128°N 0.217561°WCoordinates: 51°30′18″N 0°13′03″W / 51.505128°N 0.217561°W
London Transport portal UK Railways portal

Shepherd's Bush station is a railway station located in the district of Shepherd's Bush in west London, England, UK. It opened in 2008 on the West London Line and is served by London Overground and Southern rail services. It lies within Travelcard Zone 2.

A number of stations in the area both past and present have borne the name Shepherd's Bush; today the National Rail station shares its name with the adjacent Central line Shepherd's Bush, with which it shares a surface-level interchange.

An entirely separate London Underground station, Shepherd's Bush Market on the Circle line and Hammersmith & City line is located approximately ¹⁄₃-mile (500 m) away. Until 2008, it too was called Shepherd's Bush until it was renamed Shepherd's Bush Market to avoid confusion.^[4]

History

Map showing layout of current and former railways and stations around Shepherd's Bush

Original Silverlink signage installed in 2007.

Previously a station existed almost on the same site as the present Shepherd's Bush station. Uxbridge Road station was opened in 1869 by London & North Western Railway and the Great Western Railway on the Middle Circle route. In 1905 the line became branch of the Metropolitan Railway, and later London Underground's Metropolitan line. Uxbridge Road was closed in 1940 after the line was bombed several times during the Blitz.

In 2005, construction began on a major redevelopment project in the White City area, including the large-scale Westfield Shopping Centre, developed by the Westfield Group.^[5] Shepherd's Bush station was designed and funded by the Westfield Group as part of a Section 106 redevelopment contribution, and construction was project-managed by Capita Symonds; this project also included the provision of an integrated bus interchange and the reconstruction of the London Underground Central line station.

Building work on the West London Line station began in early 2006 and it was due to open in summer 2007.^[6] Although largely completed on time, the station was unable to open due to the northbound platform being 18 inches (460 mm) too narrow to comply with railway safety regulations, based on the anticipated number of passengers using the station.^[7] Following remedial reconstruction work on the platform, the station finally opened on 28 September 2008.^[8]

The three-letter station code SPB and location code 9587 appear on ticketing systems, and train times for the station began appearing on timetables from May 2007.^[9]

With a 2007 opening date in mind, the station was to have been served by Silverlink trains, and it was fitted out with Silverlink-branded signage. By the time the station actually opened to passenger service, the rail franchise had passed to London Overground, and the station signage was rebranded.

In April 2015 the station platforms were extended to accommodate longer, 8-car Southern trains, and a footbridge and a new entrance were constructed at the northern end of the station to ease passenger flows. The £1.35m station upgrade work was supported with £3.9 million from the Westfield Shopping Centre and the platform lengthening was part of a nine-month, £25 million project funded by Network Rail to extend platforms along the West London Line.^[10][11]

Services

West London Route
Legend
West Coast Main Line Milton Keynes Central Bletchley Leighton Buzzard Tring Berkhamstead Hemel Hempstead M25 motorway Watford Junction Harrow & Wealdstone Wembley Central to Euston to Stratford Shepherd's Bush Kensington (Olympia) West Brompton Imperial Wharf River Thames Clapham Junction Wandsworth Common Balham Streatham Common Norbury Thornton Heath Selhurst East Croydon South Croydon Brighton Main Line and Oxted Line

Rail services at the station are provided by Southern between East Croydon and Milton Keynes Central and London Overground on the West London Line.

London Overground services at this station in trains per hour are:

• 4 northbound to Willesden Junction, of which 2 continue to Stratford (all continue through to Stratford at peak times).
• 4 southbound to Clapham Junction.^[12]

Southern services at this station in trains per hour are:

• 1 northbound to Milton Keynes Central via Watford Junction
• 1 southbound to South Croydon via Clapham Junction and East Croydon^[13]

Connections

London Buses routes 31, 49, 72, 94, 95, 148, 207, 220, 228, 237, 260, 272, 283, 295, 316, 607 and C1 and night route N207 serve the station and bus station.

Gallery

•
  Platforms looking north
•
  Platforms looking south
•
  Station looking north from Uxbridge Road
•
  Footbridge looking south
•
  Footbridge looking north
•
  Class 313 unit departs with a northbound Overground service
•
  Platform roundel, based on the famous symbol of London Transport, but with Overground orange circle
•
  Station entrance viewed from the south
